Patton FiberPlex SFX-10DD Data Diode SFX-SC92DR-0031-A

Patton FiberPlex SFX-10DD Data Diode

The Patton FiberPlex SFX-10DD Data Diode SFP Modules for cybersecurity have 10-gigabit optics, and facilitate one-directional data transmission for applications like file transfer, real-time data streaming, database replication, and remote monitoring. The SFX-10DD with 10-gigabit optics, features a data diode functionality, ensuring data flows in one direction only, with a single optical opening for connection.

These high-performance, cyber-secure modules support various data rates and distances, adhering to the small form-factor pluggable (SFP) multi-source agreement (MSA) and meeting RoHS compliance standards. Patton’s FiberPlex Cyber-SFP Modules are designed for digital data applications but are not recommended for digital video applications, as SMPTE encoding may lead to pathological signal errors.

Patton FiberPlex SFX-10DD Data Diode key features:

• Single LC connector
• Single direction with no possibility for a return path
• Hot-pluggable SFP footprint
• RoHS-compliant and Lead-Free
• Milled Brass enclosure for maximum EMI/RFI containment and durability
• Single +3.3V power supply
• Low power dissipation <800mW
• SFP MSA SFF-8074i Compliant.
• Designed and Manufactured in the USA
